Features
Features
1080p camera resolution providing the industry's clearest image inside of drain lines
30m (100’) 9.5 mm Push Cable provides stiffness to push maximum distance
Telescoping handle and wide wheelbase provide maximum stability
25mm self-leveling HD camera head with Sapphire lens
Onboard monitor mount for viewing and transportation
Swap batteries without system shutdown
Specifications
Specifications
Platform
M18™
Weight
12.6kg
Warranty
5 Year Tool
Drain Line Capacity
38mm - 101mm (1.5" - 4")
Cable Length
30m (100')
Camera Resolution
1080p
Sonde Frequency
512kHz, 640Hz, 33kHz
Line Type
Sewer Lines
Push Cable Diameter
9.5mm
Camera Head Ingress Protection
IP67
Video Display
M18™ Wireless Monitor or Milwaukee Pipeline Inspection App
Line Trace Frequency
33kHz, 85kHz
